Funk Tonstudiotechnik AMX-8

Optimize your studio with the Funk Tonstudiotechnik AMX-8. This 2-channel router offers professional audio matrix switching for analog stereo signals.

Product information "Funk Tonstudiotechnik AMX-8"

2-Channel Router for up to 8 Stereo Sources, 2 Independent Stereo Outputs, Alternately or Summing

Active Analog Audio Routers/Mixers
The STEREO-MATRIX AMX-8 and AMX-16 are professional, active monitoring and recording signal switches for analog stereo signals using balanced circuitry. The AMX series is among the most neutral and precise active audio matrices on the market in terms of signal purity, offering unparalleled sonic characteristics and technical specifications close to the limits of current technology.
Safety Warnings: Die spezifischen Sicherheitshinweise für das Produkt sind in dessen Bedienungsanleitung aufgeführt.

Funk Tonstudiotechnik

FUNK TONSTUDIOTECHNIK

GERMANY · 10318 BERLIN · BLOCKDAMMWEG 39-59 Tor 2

funk@funk-tonstudiotechnik.de

https://funk-tonstudiotechnik.de/

All products
  • Maximum Input Level: +24.0 dBu
  • Input Impedance: 20 kΩ balanced
  • Common-Mode Rejection (balanced inputs) 1 kHz/10 kHz: > 60 dB/60 dB (typ. ≥70 dB)
  • Maximum Output Level: +24.0 dBu at 10 kΩ
  • Output Impedance: 2x 22 Ω
  • Output Voltage Symmetry: > 75 dB/1 kHz > 75 dB/10 kHz
  • Output Impedance Symmetry: > 65 dB/1 kHz > 60 dB/10 kHz
  • Maximum Output Load Balanced Outputs: 600 Ω at +22 dBu / 300 Ω at +18 dBu
  • Frequency Response: 10 Hz ...20 kHz < ± 0.01 dB, 1 Hz...200 kHz < ± 0.2 dB
  • Large Signal Bandwidth: 1 Hz...100 kHz < ± 0.2 dB
  • Phase Response Absolute: 20 Hz ...20 kHz < ± 3.5°
  • Phase Response Relative Left ↔ Right: 20 Hz ...20 kHz < ± 1°
  • Nonlinear Distortion (THD): 1 kHz < 0.0002 %, typ. 0.00008 % (1 kHz < 0.0003 %)
  • Nonlinear Distortion + N (THD+N): 1 kHz < 0.0005 %, 10 kHz 0.001 %
  • Difference Tone Distortion 10.5 kHz Δf 1 kHz: < 0.00008 % (< 0.0002 %)
  • Intermodulation 60 Hz/8 kHz: < 0.0005 % (< 0.0008 %)
  • Crosstalk Input/Input: 1 kHz > 135 dB, 10 kHz > 115 dB
  • Crosstalk Matrix A ↔ Matrix B: 1 kHz > 128 dB, 10 kHz > 112 dB
  • Gain Input → Output: +0.0 dB (additional 0..+12 dB internally adjustable)
  • Gain Deviation Input/Input: < ± 0.02 dB, typ. < 0.01 dB
  • Noise Voltage Rated: -92.0 dBu CCIR 468 qp -98.0 dB (Ref. +6 dBu)
  • Unweighted Foreign Voltage: -103.0 dBu 20 Hz..22 kHz eff. -109.0 dB (Ref. +6 dBu)
  • Foreign Voltage Output at A-weighting eff: -106.5 dBu -112.5 dB (Ref. +6 dBu)
  • Noise Voltage MIX Mode 4 / 8 / 16 Inputs Summed Rated: -86.8 dBu / -83.5 dBu / -80.4 dBu CCIR 468 qp
  • Foreign Voltage MIX Mode 4 / 8 / 16 Inputs Summed Unweighted: -97.9 dBu / -94.8 dBu / -91.8 dBu 20 Hz..20 kHz eff.
  • Dynamic Range: > 127 dB unweighted eff. 130.5 dB A-weighted eff.
  • Clip Indicator Switching Threshold: +23.0 dBu
  • Power Supply: 90...260V / 45..400 Hz
  • Typical Power Consumption: 9 W AMX-8, 12W AMX-16
  • Protection Class: 1
  • Dimensions Main Unit: 19 inch/1U 483 x 44 x 250 mm, Weight: 3.5 kg
  • Dimensions Remote Control: 19 inch/1U 483 x 44 x 50 mm, Weight: 0.6 kg
