UK Sound 73MP Single Channel Mic Pre
Product information "UK Sound 73MP Single Channel Mic Pre"
This is the mic pre-amp version of the 1073 equaliser having the same well-known characteristic Class A sound with its harmonically rich low end, slight resonant highs, and maintained focused mids.
OEP Carnhill transformer coupled input, with two selectable impedances makes the 73MP work well with a variety of microphones.
There is also a line input feature for adding depth to 2-bus mixes and a DI input for all passive and active instruments.
As a coloured and versatile mic-pre, the 73MP maintains its sonic signature across a wide bandwidth.
| Safety Warnings: | Die spezifischen Sicherheitshinweise für das Produkt sind in dessen Bedienungsanleitung aufgeführt. |
|---|
UK Sound
Frequency Response
6Hz to -3dB at 75kHz
Flat within 0.5dB between 20Hz and 20kHz
Mic Input Impedance
≈600/150 ohms
Line Input Impedance
10k ohms
DI Input Impedance
≈150k ohms
Output Impedance
65 ohms
Common Mode Rejection Ratio
100dB min @ 60Hz
Maximum Output Level
+27.4 dBu @ 600Ω
Power Requirements
115/230 VAC, 30W
Gain dB
0 to 71 dB
Equivalent Input Noise
-110 dBu; Unweighted 300kHz Bandwidth
Weight (Single/Dual)
5 LBS/2.27 KG
7 LBS/3.18 KG
Dimensions (Inches)
19W x 1.75L x 9D
