Tk Audio TK‐lizer 3
- Three bands with 6 frequencies each.
- High and low bands selectable between shelf or peak.
- High pass filter with 12 frequencies.
- M/S function for separate processing of mid and side channels.
- Electronically balanced for a clean path.
- Cue switch for monitoring of left/right or mid/side channels.
- All controls stepped for easy recall and precise settings.
Product information "Tk Audio TK‐lizer 3"
The TK-lizer 3 is a mastering and mixing equalizer based on the renowned Baxandall circuit, known for its smooth and natural sound character. It features three frequency bands with selectable frequencies, switchable peak and shelving filters, a high-pass filter, and dedicated gain controls for precise tonal shaping. In addition to standard Left/Right processing, it offers advanced Mid/Side functionality for stereo width adjustment, side-channel EQ processing, and low-frequency mono compatibility. Compared to its predecessor, the TK-lizer 3 includes redesigned audio circuitry, improved channel separation, and a refined vintage-inspired design with Bakelite knobs and toggle switches.
| Safety Warnings: | The specific safety instructions for the product are provided in its user manual. |
|---|
TK Audio
TK Audio
Musikverkstan i Halmstad AB Falkenbergsgatan 10 302 33 Halmstad Sweden
https://tkaudio.se/
- Input impedance: 20kohm
- Output impedance: 68ohm
- Max input level: +27dBu
- Max output level: +28dBu
- Frequency response: 20Hz – 80kHz +/-0,1dB
- THD+N at 0dBu: 0,0004%
- S/N @ 0dBu: 95dB
- Dynamic range: 123dB
- Channel separation M/S: better than 60dB at 0dBu
- No electrolytic capacitors in the audio path
- Power consumption: 10VA
- Voltage: 115v or 230v selected via an internal voltage selector
