Pulse Techniques EQH-2
- Compact design version of the classic EQP-1
- Identical low-frequency boost/attenuation curves to EQP-1A
- Comparable high-frequency peak boost centers to EQP-1A
- Fixed bandwidth for HF peak boost
- Fixed HF attenuation at 10 kHz
- Minimalist Class A line amp output stage (same as MEQ-5)
- Renowned for transparent sound, preferred by top engineers
Product information "Pulse Techniques EQH-2"
First introduced in 1956, the EQH-2 was designed as a more compact alternative to the 3U EQP-1. Retaining the same low-frequency boost/attenuation curves as the EQP-1A, and with high-frequency peak boost centers closely aligned, the EQH-2 delivers the classic Pultec sound in a streamlined format. Featuring a fixed bandwidth for high-frequency boost and a fixed 10 kHz high-frequency attenuation, it maintains the simplicity and musicality that made the originals legendary. Its minimalist Class A output stage, shared with the MEQ-5, is celebrated for its transparency, making the EQH-2 a favorite among top engineers including Dave Cobb and Michael Dumas.
Pulse Techniques
PULSE TECHNIQUES, LLC
PO BOX 273046 FORT COLLINS, CO 80527
support@pultec.com
https://pulsetechniques.com/
Shelf Boost:
- 20, 30, 60, 100 CPS, 0 – 13.5 dB
Shelf Attenuate:
- 20, 30, 60, 100 CPS, 0 – 17.5 dB
- 10 KCS, 0 – 16 dB
Peak Boost:
- 3, 5, 8, 10, 12 KCS, 0 – 18 dB
Input Transformer: 600 Ohms
Output Transformer: 600 Ohms
Noise: Below -75 dBm
Distortion: ≤ 0.15% at +10 dBm into 600 Ohms
Amplifier: Flat, 20 CPS to 20 KCS, +0 / -1 dB, ref 1 KCS
Tubes: 1 × 12AX7, 6AQ5, 6X4
