PMC MB3S XBD-A
Discover the PMC MB3S XBD-A: Twin-cabinet speakers with Bass Radial drivers for high sound pressure levels, ideal for multi-channel arrays.
Features
- Type: 3-way ATL™ active reference monitor
- Frequency response: 20Hz-25kHz
- Power per channel: 3225W (HF 275W, MF 550W, LF & LFX 2400W)
- Effective ATL™ length: 2 x 3 metres
- Maximum SPL: 129dB
Product information "PMC MB3S XBD-A"
Featuring a second cabinet devoted exclusively to bass, with an additional single 12-inch Radial bass driver, the twin-cabinet MB3 XBD-A system offers still better dynamics than the MB3, with an additional 3dB of headroom below the bass crossover frequency of 380Hz, and allows larger rooms to be driven with an even smoother frequency response, producing a maximum SPL of 129dB. The twin XBD cabinets can be freestanding or soffit-mounted, and may be positioned vertically or side by side for greater flexibility. As with the MB3-A, a matching low-profile centre channel (MB3 XBD-C-A) is available for use in multi-channel arrays. Thanks to the wide-ranging frequency response of the twin-cabinet system, additional dedicated subwoofers are not a requirement.
| Safety Warnings: | Die spezifischen Sicherheitshinweise für das Produkt sind in dessen Bedienungsanleitung aufgeführt. |
|---|
PMC
The Professional Monitor Company Limited
Holme Court, Biggleswade, Bedfordshire, SG18 9ST
marketing@pmc-speakers.com
https://pmc-speakers.com
Frequency Response:20Hz - 25kHzSensitivity:Adjustable +4 to +20dBuEffective ATL™ Length:2 x 3m (10ft)Impedance:Input Impedance 20k BalPeak SPL:129dB @ 1mDrive Units:
LF - 2 x PMC 310mm (12-inch) Radial driver
MF - PMC hand built 75mm soft-dome driver
HF - PMC 34mm soft-dome tweeter with acoustic radiator
Crossover Frequency:380Hz & 3.8kHz
Input Connectors:AES3, 24-bit, 96kHz
Amplifier Power per Channel:LF - 1 x 2400Wrms
MF - 1 x 550Wrms
HF - 1 x 275Wrms
Dimensions:H 1740mm (68.5 “)
W 380mm (15″)
D 535mm (21″)
Weight:88kg (194 lbs) each
