Product information "Milab VIP-50 (matched pair)"
The Milab VIP-50 is nothing less than a true classic. A favourite among world class artists and producers - simply one of the most sophisticated vocal recording microphones ever made.
Features:
- Transformerless
- Variable pattern
- 200/500 Hz high pass filters
- 10/20 dB attenuation pad
- Rectangular large dual membrane capsule
- Shock absorbing rubber fitted capsule
- Gold-plated XLR connector
- 48 V phantom
- Nextel® coating (from 2012)
Safety Warnings: | Die spezifischen Sicherheitshinweise für das Produkt sind in dessen Bedienungsanleitung aufgeführt. |
---|
Milab
Milab Microphones AB
Gevärsgatan 20 SE-254 66 Helsingborg SWEDEN
milab@milabmic.com
https://www.milabmic.com/
Product name | Milab VIP-50 | |
Type | Condenser | |
Article number | 1111 | |
Frequency response | 20 to 20,000 Hz - View curve | |
Polar pattern | Cardioid - View diagram Wide cardioid - View diagram Hypercardioid - View diagram Figure eight - View diagram Omni - View diagram | |
Filters | 200 Hz & 500 Hz (switchable) | |
Pre-attenuation pad | -10 dB & -20 dB (switchable) | |
Max. SPL (1% THD at 1 kHz) | 112 dB | |
Max. SPL with 10 dB pad | 122 dB | |
Max. SPL with 20 dB pad | 132 dB | |
Sensitivity at 1 kHz | 14 mV/Pa (± 1dB) | |
A-weighted noise level (IEC 179-A) | 19 dB | |
Power supply | 48 ± 4 V Phantom (DIN/IEC) | |
Current consumption | 3,5 mA | |
Output impedance | <200 Ω | |
Minimum load impedance | 1 kΩ | |
Connection | 3-pin XLR | |
Net weight | 400 g | |
Length | 170 mm | |
Width | 47 mm | |
Depth | 50 mm |
