Lake People ANA-TOOL F811
Product information "Lake People ANA-TOOL F811"
8-ch BALANCING AMPLIFIER F811 Balancing, impedance and level matching unit for interfacing between consumer- and studio equipment.
- - 2 x 4 identical sections from consumer level to studio level- Rear inputs via Cinch (RCA) sockets
- - Front inputs via Cinch (RCA) sockets with priority- All inputs with gold plated contacts- Inputs optimized for “
- -10 dBu” signals- Impedance 50 kohms- Internal filters to reduce the bandwidth to a safe and useful range: 5 Hz … 40 kHz (-1 dB)
- - Front accessible multiturn trimpots for level adjustment with a range from -3 … +21 dB
- - Balancing of the output signals with optimized circuits for highest resistance- and common mode rejection ratio (CMRR)
- - Output impedance 30 Ohms according to IRT rules- XLR type output sockets with gold plated contacts
- - 19”, 1 U stainless steel case, front color dark grey
Option: Transformer outputs with “active feedback” transformers
Specifications:
- Channels: 2 x 4
- Input impedance: 50 kohms
- Max. input level: > +21 dBu
- Gain: -3 ... +21 dB
- Frequency range: 5 Hz ...40 kHz ( -1 dB)
- THD+N: < -100 dB (@ +6 dBu, 0 dB Gain)
- Noise: < -100 dBu (@ 0 dB Gain, unwtd.)
- Crosstalk: < -100 dB @ 15 kHz
- Max. output level: > +25 dBu
- Output CMRR: > 70 dB @ 15 kHz
- Output impedance: 30 ohms
- Power supply: 115 / 230 VAC, 15 VA
- Dimensions: 483x44x166 mm (WxHxD), 19",
- 1U Case: Stainless steel Finish: Front dark grey
| Safety Warnings: | Die spezifischen Sicherheitshinweise für das Produkt sind in dessen Bedienungsanleitung aufgeführt. |
|---|
