Hear Technologies Switch Back PLUS
- 64-channel Dante mixing – blend up to 64 Dante channels plus 4 local inputs to stereo line outputs and dual headphone outputs
- Dante transmission – send stereo mix and local inputs (mic, instrument, line 1 & 2) to other Dante devices
- Zero-latency monitoring – real-time monitoring of all local inputs
- Intercom functionality – discrete Dante channels for local inputs, unmuted via the broadcast button
- Signal indication – visual signal presence on all channels
- MIDI control capability – knobs can send and receive MIDI CC messages for network-based control
Product information "Hear Technologies Switch Back PLUS"
A Dante audio interface, mixer, and MIDI control surface in a single device. Simply connect via a Cat6 Ethernet cable to a PoE+ network switch and route audio to and from your Dante-enabled devices – whether it’s a front-of-house console or a laptop running Dante Virtual Soundcard.
Add multiple PLUS units to scale and decentralize your audio inputs or provide each band member with their own personal monitor mixer.
The device can also be used as a MIDI controller, allowing you to adjust parameters of external instruments and effects with precision.
From studio environments to live stage setups, the Switch Back PLUS integrates effortlessly into a wide range of workflows.
With seamless Dante connectivity, setup is simple and audio performance remains crystal clear in any application.
| Safety Warnings: | The specific safety instructions for the product are provided in its user manual. |
|---|
Hear Technologies
- Technical Data:
- Microphone Input (Analog → Dante @ 48 kHz)
- Configuration: XLR mono, balanced, 3 kΩ
- Frequency response: 20 Hz – 20 kHz (±0.85 dB), 30 Hz – 20 kHz (±0.32 dB)
- THD+N: 0.003% @ 150 mV, +24 dB gain
- IMD: 0.01%
- Crosstalk: -106 dB
- Sensitivity (max gain): -36 dBu → 0 dBFS
- Sensitivity (min gain): +13.8 dBu → 0 dBFS
- Instrument Input (Analog → Dante @ 48 kHz)
- Configuration: 1/4" TS, unbalanced, 1 MΩ
- Frequency response: 20 Hz – 20 kHz (±0.76 dB), 30 Hz – 20 kHz (±0.33 dB)
- THD+N: 0.003% @ 150 mV, +12 dB gain
- IMD: 0.006%
- Crosstalk: -82 dB
- Sensitivity (max gain): -33.5 dBu → 0 dBFS
- Sensitivity (min gain): -1 dBu → 0 dBFS
- Line Inputs 1 & 2 (Analog → Dante @ 48 kHz)
- Configuration: 1/4" TRS, balanced, 20 kΩ
- Frequency response: 20 Hz – 20 kHz (±0.74 dB), 30 Hz – 20 kHz (±0.32 dB)
- THD+N: 0.005% @ 1 V
- IMD: 0.008%
- Crosstalk: -99 dB
- Sensitivity: +18 dBu (fixed)
- Propagation Delay
- Analog → Dante: 0.542 ms (48 kHz), 0.396 ms (96 kHz), 0.318 ms (192 kHz)
- Analog → Analog: 0.662 ms (48 kHz), 0.349 ms (96 kHz), 0.182 ms (192 kHz)
- Analog Outputs
- Frequency response: 20 Hz – 20 kHz (±0.15 dB)
- THD+N: 0.005% @ +18 dBu
- IMD: 0.009%
- Crosstalk: -94 dB
- Noise: -92 dBu
- Dynamic range: 112.6 dB (HP), 114.3 dB (line)
- SNR: 100.5 dB (HP), 105 dB (line)
- Dante → analog delay: 0.792 ms (48 kHz), 0.563 ms (96 kHz), 0.438 ms (192 kHz)
- Physical
- Dimensions: 241 × 151 × 69 mm
- Weight: 0.72 kg
- Mounting: mic stand (5/8") or desktop
- Power
- PoE+: 36–52 VDC, max 15 W
