Lab.gruppen PLM 10000Q

The PLM 10000Q amplifier is based on technology from Lab.gruppen's highly acclaimed and road-proven FP+ series, but goes the extra mile for even greater sustained output power: an impressive 4 x 2,300 watts! Basically, the power amplifier technology is Lab.gruppen's patented Class TD amplifier design that offers the proven efficiency of Class D amplification with the amazing, sonic purity of Class B designs, but that is not all. A new circuit provides substantially greater current-carrying capabilities, and the Regulated Switch Mode Power Supply (R.SMPS) is optimized to deliver full power during long low-frequency bursts as well as maintain stable rail voltages despite fluctuating line voltage. Further, PLM 10000Q offers extreme power density, patented intercooler cooling, a full suite of protection features and a Power Average Limiter (PAL) that prevents tripping of mains breakers. Finally, advanced cross-overs inside the PLM 10000Q feed its four output stages, allowing for optimized RMS and true-peak limiter settings for the lo and mid/hi drivers.

In other words, the PLM 10000Q amplifier delivers exactly the kind of pure and reliable power that is worthy of a set of high-end monitors such as Dynaudio Acoustic's M3A.

Lab.gruppen PLM 10000Q main features and specifications

• 2350 W per channel @ 2 ohms, 2300 W per channel @ 4 ohms, 1300 W per channel @ 8 ohms**
• 2 unit 19" chassis weighing only 13.5 kg
• Input connection: Analog, Digital, Dante
• Class TD® output stage
• Regulated Switch Mode Power Supply (R.SMPS™)
• Copper-finned Intercooler® with transverse-mounted output devices
• Full suite of protection and fault monitoring features
• Digitally controlled 'amplifier gain' adjustable in 0.1 dB steps from 22 to 44 dB
• Digital output attenuation in 0. 25 dB steps from -inf to 0 dB
• Digitally implemented, zero-overshoot Inter-Sample Voltage Peak Limiting (ISVPL™) adjustable in 0.1 V steps from 17.8 to 153 V
• Power Average Limiter (PAL)

Lake processing

Having the perfect monitors and amplifier is one thing. Making them deliver divine audio quality in any room is another - and this is where unique Lake processing makes all the difference. Lab-gruppen's PLM 10000Q amplifers holds two full-featured Lake Processor modules, each offering precise settings for gain, delay, crossover slope, equalization and limiting that provide you with unparalleled power to correct, shape and optimize your sound in any control room.

Exclusive Lake Processing algorithms are included for Raised Cosine Equalization, linear phase crossovers, LimiterMax loudspeaker protection, and Iso-Float ground isolation. Raised Cosine Equalization is the foundation for the Lake Mesa EQ and the Ideal Graphic EQ, the two revolutionary EQ interfaces used by the Dolby Lake Processor. Mesa EQ offers asymmetric filtering to match the asymmetric responses of many loudspeaker systems while the Ideal Graphic EQ offers true sum-to-flat response, so the adjustments provide uniform boost and cut along with greater selectivity.
