AMS Neve 1073 DPX-D

€4,469.00*

This product will be released on 1 April 2026

Manufacturer: AMS Neve

Features

Two complete 1073 channel strips in a 2U 19" rack format
Discrete Class-A circuitry for the signature Neve sound
Newly designed transformer-balanced DI stage delivering classic Marinair harmonics
High-resolution AD/DA conversion up to 192 kHz / 24-bit to complement the legendary analog 1073 circuitry

Product information "AMS Neve 1073 DPX-D"

The 1073DPX-D combines two full 1073 channel strips with a high-quality USB/ADAT audio interface offering 10 inputs and 12 outputs, bringing the unmistakable character of the iconic microphone preamp directly into modern DAW-based workflows. Designed and hand-built in England, it features a fully discrete Class-A signal path, transformer-coupled tone stages, an inductor-based EQ, and seamless digital integration—all housed in a rugged 2U 19-inch rack enclosure. Supporting dual-mono and stereo tracking, digital re-amping, hardware insert routing, advanced monitoring, and scalable ADAT expansion, the 1073DPX-D is engineered to serve as the central hub for professional studios, project studios, and mobile recording setups.

Safety Warnings:	Die spezifischen Sicherheitshinweise für das Produkt sind in dessen Bedienungsanleitung aufgeführt.

AMS Neve

AMS Neve Ltd,

AMS Technology Park, Billington Road, Burnley, Lancashire, BB11 5UB

info@ams-neve.com

https://www.ams-neve.com/

All products

Microphone Inputs

Frequency Response (20 Hz – 20 kHz): ±0.4 dB
THD: <0.2%, 20 Hz – 20 kHz; <0.02% @ 1 kHz
Noise (EIN): <-124.5 dBu, 20 Hz – 20 kHz, unweighted, gain @ 60 dB
Gain Range: 20 – 80 dB
Maximum Input Level (max gain @ 80 dB): -52 dBu
Maximum Input Level (min gain @ 20 dB): +26 dBu
Input Impedance: 10 kΩ / 300 Ω

Line Inputs

Frequency Response (20 Hz – 20 kHz): ±0.4 dB
THD: <0.2%, 20 Hz – 20 kHz; <0.02% @ 1 kHz
Noise (EIN): <-100 dBu, 20 Hz – 20 kHz, unweighted, gain @ 20 dB
Gain Range: -10 – +20 dB
Maximum Input Level (max gain @ 20 dB): +6 dBu
Maximum Input Level (min gain @ -10 dB): +36 dBu
Input Impedance: 10 kΩ

DI Inputs

Frequency Response (20 Hz – 20 kHz): ±0.5 dB
THD: <0.2%, 20 Hz – 20 kHz; <0.02% @ 1 kHz
Gain Range: 20 – 80 dB (without pad)
Maximum Input Level (max gain @ 80 dB): -56 dBu
Maximum Input Level (min gain @ 20 dB): +6 dBu
Input Impedance: 2 MΩ / 200 kΩ

Insert Send / Return

Maximum Input and Output Level: +26 dBu

Monitor Outputs

Maximum Output Level: +20 dBu

Headphone Output (600 Ω load)

Maximum Output Level: +14 dBu
Frequency Response: 10 Hz – 30 kHz, ±0.1 dB
THD: 0.005%
Noise Floor: -90 dBu

General

Dimensions: 48.0 × 36.0 × 8.8 cm (L × W × H), 2U / 19"
Weight: 5.5 kg
